Antifreeze NF

Kühlerschutz Konzentrat (Farbe: blau)

Customs no.: 38200000

Description

Antifreeze NF is a full concentrate coolant based on monoethylene glycol for summer and winter operation with frost and rust protection effect (year‑round use). Antifreeze NF The high‑performance, anti‑corrosion antifreeze for the engine and cooling system meets modern requirements in the development of engine construction. Antifreeze NF is free of nitrite, amine and phosphate.

Properties

compatibility with varnishes
Prevention of cavitation damage, e.g. on the coolant pump
Avoiding deposits that can lead to radiator blockages
foam prevention
Compatibility with hose and sealing materials
Protection against corrosion for all components of the cooling system made of steel, gray cast iron, aluminum, copper, brass, soft solder.

Suitable for/ we recommend this product for

BS	6580
SAE	J 1034
AFNOR	NF‑R 15‑601 Type 1
ASTM	D 3306, D 4985

We recommend this product for

ÖNORM	V 5123
JIS	K 2234
UNE	26‑361
AS	2108
CUNA	NC 956‑16

Use

Antifreeze ANF 40 is ideal for aluminum, light metal and gray cast iron engines thanks to the specially used additives.
Recommended application concentration 50% Antifreeze ANF 40 and 50% water, whereby frost protection down to approx. ‑38°C is achieved. With a maximum of 68% Antifreeze ANF 40 and 32% water, frost protection down to ‑69°C is possible.
Depending on the type and manufacturer, the contents of the cooling system should be replaced every 2 to 3 years.
Can be used in hybrid vehicles and battery‑powered electric vehicles provided there are no requirements for electrical conductivity.
Manufacturer instructions must always be observed.

Miscibility

Antifreeze NF is miscible with most ethylene glycol based coolants. For optimum corrosion protection and to prevent sludge formation, the unmixed use of Antifreeze NF recommended. Softened water should preferably be used to prepare mixtures.

Typical values

color		blue
Flash point COC	°C	>120
pH value	(33 vol.%)	7.5‑8.5
foaming behavior		corresponds
boiling point	°C	165
Specific gravity at 20°C	kg/m³	1.110 ‑ 1.140
Pour point antifreeze/water=1:1	°C	‑38
water content	%	<5
