Description

CORONA XHI is a new generation low SAPS‑HC‑synthesis low‑friction multigrade engine oil. The exceptional properties of this high‑performance engine oil meet today's requirements and operating conditions. It is optimally tailored to extended oil change intervals. Due to its special composition, this engine oil is ideally suited to several new OEM requirements. These properties ensure use in petrol and diesel engines in cars and vans with and without turbochargers, as well as with and without exhaust aftertreatment systems (diesel particulate filters). The "Low Ash" (Low SAP) formula protects the engine and the catalytic converter system. This engine oil is also suitable for car diesel engines with pump/nozzle injection systems (PD).

Properties

  • Excellent viscosity‑temperature behavior

  • Low evaporation loss
  • Very high cleaning effect
  • Extreme wear protection under all operating conditions
  • High oxidation and temperature stability
  • Maximum shear stability
  • Minimal friction losses, more engine power

Effects

  • year‑round use

  • With fuel‑saving and low ash formula
  • Stable oil pressure
  • Reduces fuel consumption and reduces exhaust emissions
  • High performance reserves and high product stability, even with the longest oil change intervals
  • prevention of deposits
  • Excellent cold start performance ‑ fast supply of all lubrication points, especially the hydraulic tappets
  • Perfect long‑lasting engine cleanliness
  • Low sulfur, phosphorus and ash content

Suitable for/ we recommend this product for

SAE

5W‑40

ACEA

C3

API

SN Plus/CF

We recommend this product for

BMW

Longlife‑04
FIAT9.55535‑S2
FORD WSS‑M2C917‑A
GMDexos 2
MB226.5
MB229.31
MB229.51
PORSCHE A40
RENAULTRN0700/0710
VW505.01, 502.00, 505.00

Utilization

  • with multi‑valve technology

  • high‑performance and normal four‑stroke gasoline engines
  • direct injection
  • high‑performance passenger car diesel engines
  • CDI and TDI engines
  • with catalyst technology
  • pump‑nozzle
  • with turbocharging
  • with Common Rail diesel technology
  • with Valvetronic
  • with intercooling
  • with diesel particulate filter systems (DPF)

Disposal

CORONA XHI is assigned to used oil category 2 and is therefore safe for disposal.

Miscibility

CORONA XHI is fully compatible with conventional HD oils and can be mixed safely. To benefit from the advantages of CORONA XHI However, to fully exploit it, it is recommended CORONA XHI to use.

Typical values

Viscosity at 40°Cmm²/s79
Viscosity at 100°Cmm²/s13.5
sulphate ash%
Flash point COC°C232
TBNmgKOH/g8.0
viscosity index175
Specific gravity at 15°Ckg/m³850
Pour point°C‑42
Dynamic viscosity at ‑30°CmPa.s5250

Articles

1 Liter Can

Art.-Nr.: 1209 222

4 Liter Jug or Can

Art.-Nr.: 1209 223

5 Liter Jug or Can

Art.-Nr.: 1209 224

20 Liter Jug or Can

Art.-Nr.: 1209 225

60 Liter Barrel

Art.-Nr.: 1209 226

200 Liter Barrel

Art.-Nr.: 1209 228

1000 Liter Container

Art.-Nr.: 1249 229

Downloads

Revision: 28. November 2025
